The new waterproof WAT-400D camera utilizes true color producing technology housed in a fully submergable housing. With over 450TVL of color resolution this camera is the perfect choice for your outside use applications.
Watec WAT-400D Camera Features:
* Built-in lens automatic white balance;
* Resolution: 450TVL;
* Minimum illumination 2.0Lx. F1.6;
* Waterproof IPX8.
* One-cable system (Video/power transmission)
Watec WAT-400D Camera Specifications:
| Model |
WAT-400D(NTSC) |
WAT-400D(PAL) |
| Image Sensor |
1/3" CCD |
| total pixels |
811(H)*508(V) |
795(H)*596(V) |
| Effective Pixels |
768(H)*494(V) |
752(H)*582(V) |
| Pixel Size |
6.4um(H)*7.5um(V) |
6.5um(H)*6.3um(V) |
| imaging system |
Ye, Cy, Mg, and G complementary color mosaic filters on chip |
| Synchronization mode |
internal synchronization |
| Scanning system |
2:1 interlaced scanning |
| video output |
synthesize,Y/C£º1.0 V(P-P),75¦¸,imbalance |
| resolution ratio(H) |
More than 450 TVL(Center) |
| minimum illumination |
2.0lx. F1.6 |
| S/N |
More than 50dB(AGC=3dB,¦Ã= 1.0) |
| AE (automatic exposure) |
1/60 sec. |
1/50 sec. |
| WB |
ATW |
| automatic gain control |
3-24dB |
| Gamma Features : |
¦Ã¨P0.45 |
| BLC |
ON |
| Power voltage |
DC + 15V¡À10% |
| power consumption |
2.03W(135mA) |
| Maximum cable length |
RG-58/U,200m |
| Built-in cable length |
RG-58/U,10m |
| Operating Temperature |
-10 - +50¡æ(Frost-free knot) |
| Storage Temperature |
-30 - +70¡æ(Frost-free knot) |
| Work /Storage humidity |
Lower than 95£¥RH |
| Built-Lens |
Auto iris lens control (F = 2.8 F =1.6) |
| Weight |
About 900G(Including the RG-58/U 10m cable) |
Optional factory Settings
| Model |
WAT-400D£¨NTSC£© |
WAT-400D£¨PAL£© |
| AE |
Adjustable shutter
speed |
1/60,1/100 sec. |
1/50,1/120 sec. |
| 1/250,1/500,1/1000,1/2000,1/5000,1/10000,1/20000,1/50000.sec |
| WB |
ATW,Preset(3200K,5100K,8200K) |
| Mirror Horizontally |
ON/OFF |
* Maximum cable length should be 200 m, using RG-58 / U cables to ensure adequate electrical properties, but not guaranteed waterproof.
|
