The Watec WAT-221S is an ultra compact, high performance CCTV camera capable of producing and maintaining the level of image quality expected in demanding 24-hour security environments. This is achieved through the use of a 1/2" CCD along with a number of internal electronic controls and an auto iris function. These outstanding capabilities coupled with the camera's absolutely small size make it a particularly wise choice for applications requiring dependable yet minimally intrusive round-the-clock security monitoring.

Ultra Compact & Lightweight Body
    With a total length of about 2.5" and weighing less than 6 ounces, this is one of the smallest and lightest full featured CCTV box cameras available on the market.

Simultaneous BNC & S-Video Outputs
    Video is simultaneously outputted through the camera's BNC and S-video ports. This will allow users to view live images on a monitor connected to the twist-lock BNC port and at the same time record images to a DVR/VCR using a high quality S-video connection.

Extreme Low Light Sensitivity
    The combination of a 1/2" CCD, powerful picture controls and an auto iris function allow the camera to produce visible images in light levels as low as 0.1 lux.

Watec WAT-221S Features:
*  Illumination 0.1Lux F1.2;
*  Dual video output Y / C BNC;
*  High resolution 500 TV LINES;
*  Diversification white balance adjustment;
*  Multi-stage electronic shutter;
*  DC / VIDEO Drive automatic dimming lens;
*  Adjustable AGC GAMMA VIDEO LEVEL.

Watec WAT-221S Specifications:

Model			WAT-221S(NTSC)	WAT-221S(PAL)
Image Sensor			1/2" CCD
total pixels			811(H)*508(V)	795(H)*596(V)
Effective Pixels			768(H)*494(V)	752(H)*582(V)
Pixel Size			8.4um(H)*9.8um(V)	8.6um(H)*8.3um(V)
imaging system			Ye, Cy, Mg, and G complementary color mosaic filters on chip
Synchronization mode			internal synchronization
Scanning system			2:1 interlaced scanning
video output			synthesize,Y/C:1.0 V(P-P),75Ω,imbalance
resolution ratio(H)	synthesize		450TVL(Center)
	Y/C		480TVL(Center)
minimum illumination			0.1lx. F1.2
S/N			More than 50dB(AGC=8dB,γ= 1.0)
AE Mode		Fixed	1/60 - 1/100 sec.	1/50 - 1/120 sec.
			1/250,1/500,1/1000,1/2000,1/4000,1/10000 sec.
		EI	1/60-1/100000 sec.	1/50-1/100000 sec.
			1/100 - 1/100000 sec.	1/120 - 1/100000 sec.
WB			ATW, PWB, MWB,Preset(3200K,4300K,5100K,6300K)
automatic gain control	ON		High:8-36dB / Low:8-24dB
	OFF		8 dB
Gamma Features :			γ≒0.45(On)/γ= 1.0(Off)
Image level			100IRE / 75IRE
lens			Video /DC(EIAJ arrangement,Auto-select)
BLC			ON/OFF
Power voltage			DC + 12V + -10%
power consumption			1.86W(155mA)
Operating Temperature			-10 - +40℃(Frost-free knot)
Storage Temperature			-30 - +70℃(Frost-free knot)
Work /Storage humidity			Lower than 95%RH(Frost-free knot)
Mount			CS
Weight			About 160G
