Key Features:
* Fast installation structure design, can install easily and quickly; Double layer of Die-cast Aluminum shell, can dissipate heat more sufficiently. Black inner shell makes sharper monitor
* Built-in OSD menu in English, support 20 English letters input; Display or set parameter via menu.
* Auto-identify various SONY, HITACHI, LG, CNB, SAMSUNG, etc, and auto read camera model when power on.
* The first designer of wide voltage in domestic, DC12V~AC24V, no need to identify “+” or “-”;
* Soft address design can alter long-distance ID address code, no need manual dial-up.
* Show and Edit title function containing 20 English letters, can independently set the titles for camera itself, Preset Position, Pattern Scan, Auto-level Scan and Zone display.
* Auto flip with vertical 180° in Omni-directions, no fade zone.
* 200 preset position with editable title; 4 patrol tracking routes, each can insert 32 spots.
* 4 Pattern scan routes, each can record 1000 consecutive moves, the time up to 10 minutes.
* 4 auto levels scan routes with left & right spacing, speed can set.
* Position-indicating function, temperature indicator function, information display function, information query function
* 8 dynamic privacy zone can setup.
* 8 display zones with editable title.
* Alarm system with 4 input and 2 output channel and support the linkage (recall presets and various of scan mode. Tracking, Pattern, Auto-level scan);
* Auto activation at fixed time, and can auto execute different scans and presets after a given leisure time.
* RS485 control, integrated various of protocols, PELCO-D, PELCO-P etc.
* 3 class lightning defend, built in 3000V lightning proof, surge resistant.
* IP 66 outer cover with all day protection; Built-in auto thermostatic control system with patent
